Motor Power | 2200W |
Motor Speed | 2800(50Hz), 3300(60Hz) |
Conveyor Belt Drive Motor | 400W |
Roller Size | dia 127mm x 465mm |
Feeder Sanding Belt Size | 1420mm x 460mm |
Work Table Dimension | 540mm x 470mm |
Feeding Speed | Variable |
Dust Hood Dia | 100mm |
Min-Max Workpiece Height | 5mm-100mm |
Working Width | 460mm |
The heavy, stable structure enables the processing of elements up to 100 mm high
* Innovative technology, shaft rotation up to 2800 rpm, allow for processing wood and metal.
* Massive construction much heavier than the previous version
* Reinforced side guide of the grinding shaft improving stiffness and high accuracy of the ground detail on the surface of 460 (920) mm
* Metal clutch transmitting power from the motor to the grinding shaft
* Precise mechanical gauge for easy reading of the desired grinding thickness
* The sanding cylinder made of drawn aluminum is precisely balanced and self-cooling included with the machine as standard
