| Model | DS18A | DS18 |
| Motor Power | 2200W | 1500W |
| Motor Speed | 2800(50Hz), 3300(60Hz) | 2800(50Hz), 3300(60Hz) |
| Conveyor Belt Drive Motor | 400W | 60W |
| Roller Sanding Belt Size | 1995mm x 100mm | 2100mm x 75mm |
| Roller size | dia 127mm x 465mm | dia 100mm x 465mm |
| Feeder Sanding Belt Size | 1420mm x 460mm | 1120mm x 450mm |
| Work Table Dimension | 540mm x 470mm | 460mm x 465mm |
| Feeding speed | Variable | 0~4m/min |
| Dust Hood Dia | 100mm | 62mm |
| Maximum grinding feed | 0.2mm | 0.5mm |
| Min-Max Workpiece Height | 5mm-100mm | 5mm-100mm |
| Working Width | 460mm | 460mm |
The heavy, stable structure enables the processing of elements up to 100 mm high
* Innovative technology, shaft rotation up to 2800 rpm, allow for processing wood and metal.
* Massive construction much heavier than the previous version
* Reinforced side guide of the grinding shaft improving stiffness and high accuracy of the ground detail on the surface of 460 (920) mm
* Metal clutch transmitting power from the motor to the grinding shaft
* Precise mechanical gauge for easy reading of the desired grinding thickness
* The sanding cylinder made of drawn aluminum is precisely balanced and self-cooling included with the machine as standard
