| Model | |||
| Belt size(mm) | 75x2000 | 150x2000 | 100x1220 |
| Motor speed(rpm) Single speed motor | 2800 | 2800 | 2800 |
| Belt speed(m/s)Single speed motor | 30 | 30 | 19 |
| Motor speed(rpm) Two speed motor | 2800/1400 | 2800/1400 | 2800/1400 |
| Belt speed (m/s) Two speed motor | 30/15 | 30/15 | 19/9.5 |
| Working desk size(mm) | 460x75 | 460x150 | 275x100 |
| With gear(mm) | 200/76 | 200/155 | 172/100 |
| Motor power | 230V | 230V | 230V |
| Single speed/Two speed | 2.2/2.6/(1.5/2.0) | 2.8/3.5/(2.4/2.8) | 1.5/1.5/(0.9/1.3) |
| Package dimensions(mm) | 1000x480x580 | 1000x540x610 | 630x420x430 |
| Weight(kg) | 79/63 | 98/81 | 39/34 |
Tips: Fill in the message before you can get the product parameter manual
