| Model | OM-BS16 | OM-BS18 | OM-BS20 | OM-BS24 |
| Motor power(output) | 3HP | 3HP | 3HP | 4HP |
| Blade length | 2910mm | 340mm | 3520mm | 4080mm |
| Blade width | 6-25mm | 0.6-40mm | 6-25mm | 0.65-40mm |
| Blade speed | 480/820m/min | 10m/sec | 480/820m/min | 10m/sec |
| Max depth of cut | 300mm | 330mm | 300mm | 310mm |
| Max width of cut | 370mm | 445mm | 470mm | 560mm |
| Table size | 500x400mm | 595x495mm | 500x400mm | 595x495mm |
| Table tilt | 0-45° | 0-45° | 0-45° | 0-45° |
| Bandsaw wheel Dia. | 422mm | 460mm | 422mm | 600mm |
| Dust port | 100mm | 100mm | 100mm | 100mm |
* Large cast iron table provides a strong and steady work area to support large workpiece
* Cast iron bandwheels are dynamically balanced and provide a flywheel effect for improved cutting performance
* Solid double trunnion table mount for rigid table support featuring one handed rack pinion table tilt for ease of use and accuracy
Tips: Fill in the message before you can get the product parameter manual
