| Model | OM-TS10 | OM-TS10S |
| Motor power | 4HP | 2HP |
| Main table size | 1020mm x 686mm | 635mm x 430mm |
| With table extensions | 305mm x 686mm | 635mm x 1030mm |
| Saw blade / bore size ф | 15.875mm arbor, 254mm dia. | 30mm arbor, 254mm dia. |
| Blade speed | 3550RPM | 4750RPM |
| Maxdepth of cut at 90 degrees | 80mm | 82mm |
| Maxdepth of cut at 45 degrees | 55mm | 60mm |
| Dust port | 100mm |
* Cast iron table and sliding table, 3000W induction motor fitted
