| MODEL | OM-GT18 | OMGT22 | OM-GT26 | OM-GT32 | OM-GT40 | OM-GT38 EXTRA WIDTH |
| Frame | 4 column | 4 column | 4 column | 4 column | 4 column | 4 column |
| Power | 7HP Gasoline Engine or 3HP motor | 13HP Gasoline Engine or 7.5HP motor | 13HP Gasoline Engine or 7.5HP motor | 15HP Gasoline Engine or 10HP motor | 25HP Gasoline Engine or 16HP motor | 25HP Gasoline Engine or 16HP motor |
| Blade wheel dimensions | 347mm | 480mm | 480mm | 480mm | 480mm | 480mm |
| Max log cutting diameter | 457mm | 560mm | 660mm | 815mm | 1016mm | 1150mm |
| Max board cutting capacity | width: 568mm height: 400mm | width: 660mm height: 550mm | width: 773mm height: 550mm | width: 940mm height: 720mm | width: 1016mm height: 880mm | width: 1016mm height: 880mm |
| Max cutting thickness | 180mm | 180mm | ||||
| Blade size | 2750x19mm | 3650x34mm | 3650x34mm | 4013x34mm | 4191x34x1.2mm | 4191x34x1.2mm |
| Bed length | 3m or optional length | 4m or optional length | 4m or optional length | 4m or optional length | 6m | 6m |
| Machine size | 3950x1440x1470mm | 5970x2150x1980mm | 5970x2150x1980mm | 5970x2350x2080mm | 6500x2400x2260mm | 6500x2400x2260mm |
| Package size | 1560x520x750mm | 2210x645x860mm | 2210x645x860mm | 2210x645x860mm | 2280x740x860mm | 2280x740x860mm |
| N.W./G.W. | 155/192kgs | 325/370kgs | 325/370kgs | 385/425kgs | 520/580kgs | 570/630kgs |
Tips: Fill in the message before you can get the product parameter manual
